TAC-3000, a Tower Crane Anti-Collision Control System is produced by E-Build Innovations with a core business in high-tech computer hardware development and software solution provider.

TAC-3000 is a fully computerized database managed Anti-Collision system for Tower Cranes' anti-collision and zone protection in Tower Cranes' operation on construction sites.

TAC-3000 is an easy to install anti-collision and zone protection control system for tower cranes in construction sites.

The latest user-friendly design comes with an informative Active TFT Colour LCD display for anti-collision system. It provides Anti-Collision Path Protection for construction sites with multiple tower cranes and Zone Protection from over-flying restricted zones.

TAC-3000 is a safety and efficient monitoring system which helps to prevent serious and even fatal accidents which can be caused by human error. With this efficient helping tool, it increases site productivity and a safer operating environment. However, TAC-3000 is not a fail safe safety system as the tower crane operation is still in the operator's control.

Introducing a technological sophisticated TAC-3000
TAC-3000 can communicate wirelessly between tower cranes and preset any information wirelessly through PC. It uses a 128-bit data encryption which has been incorporated into the software with a USB dongle and the TAC-3000 32-bit CPU to build a high security measure for the wireless upload.

TAC-3000 allows the site safety personnel to monitor and update the settings of the tower cranes protection wirelessly from ground level. For example, when jacking up the tower crane's height and to add additional protection zone, the site safety personnel will only require uploading the new height to the tower crane from his notebook PC without climbing up the tower crane for "re-teaching". This effectively reduces the down-time of the tower crane's operation.

Besides the advance wireless features, TAC-3000 has successfully eliminated the need to perform site "teaching" of anti-collision path. The site safety personnel just need to input the necessary information into his PC and wirelessly upload the settings to the tower cranes from ground level. This data input can be done off-site before the cranes are erected and thereafter can be uploaded once the tower cranes are ready for operation.

TAC-3000 has an exceptionally stable and accurate magnetic angle sensor that is specially designed to meet the toughest tower crane environment. This magnetic angle sensor will accurately feedback the relative jib position to the tower crane for anti-collision path detection.

The LCD display monitor installed in the operator's cabin is able to intelligently detect its own module failure and also the operation status of the other tower cranes in the same group.
